Apparatus
-
Engine 31-1
- 2016 Pierce Arrow XT
- 2,000 gpm pump
- Seating for 6
- 800 gallon water tank
- 2-1/2" portable deck monitor
- 1,000 feet of 4" supply line
- Thermal Imaging Camera
- Responds from Station #1
-
Engine 31-2
- 2004 Sutphen pumper
- 1500 gpm pump
- 750 gallon water tank
- Eight person cab
- Carries both type A and Type B foam
- Two deck monitors
- Automatic tire chain system
- 9000 watt light tower
- Air cascade system (to fill SCBA bottles) w/ four 4500 psi bottles
- Quick-lift ladder rack
-
Engine 31-3
- 1999 Sutphen Pumper
- 1500 GPM Hale Q-Max Pump
- 500 HP Detroit Diesel with Allison Automatic Transmission
- Seating for 8
- 1,200 gallon water tank
- Hale Foam Master System; Class A & B foam with 30 gallon tanks for each
- Top mounted control panel
- On spot tire chains
- Top mounted and front bumper mounted monitors
- 1,000 feet of 5" supply line
- 5000 watt Honda Generator
- Direct plumbed 5" discharge
- 8 pre-connected hose lines
- Hydraulically operated ladder rack
- Responds from station #3, Chrysler Road
-
Quint 31
- 2014 Pierce Quint
- 500 gallon tank
- 1500 gpm aerial monitor
- 750 lb. crane in ladder
- 10 KW generator
- 2000 gpm pump
- Responds from station #3, Chrysler Road
-
Tower 31
- Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab w/ a Flat Roof
- Four-Door, Six-Person Cab
- 10” Double Domex Frame Rails (110K PSI)
- Front Axle and Suspension 24,000 lbs
- Rear Axle and Suspension 52,000 lbs
- Engine: Cummins X 15, 600HP
- Alternator: Leece Neville, 420 AMP
- Transmission: Allison Gen 5, EVS4500
- QMAX-2000 GPM, Single Stage Pump
- Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
- Crosslays: (1) 2 ½” Crosslay, 2 ½” Swivel & (2) 2” Crosslays w/ 1 ½” Swivel
- 300-Gallon Water Tank
- Huckbolt #304 Stainless Steel
- Hinged Compartment Doors
- Over 280 cu ft. Total Compartment Space
- Alco-Lite Ladder Package: 121’: 14’; 16’; 16’; 30’ 2-Section; 35’ 2-Section & 10’F
- Body: SPH-3, Left 56” H / Right 56” H
- 12” Polished Stainless Steel, Bumper Extension
- Federal Q2B Siren, Grille Mount
- Intercom System: Wired Firecom 5100D, Single Radio, 6 Position
- Hannay Electric Cord Reel, 150’ (1)
- Generator: 8KW HYD
- Camera System: FRC, Inview Trueview, Single Camera
- Whelen Freedom IV 72” Lightbar
- Whelen Mini Freedom IV 21” Lightbar
- Whelen
- FireTech 12V 80” Single Brow Light
- FireTech 12V 27.2” Scene Light
- FR Spectra 240V Tele Lights
- FR Spectra 240V Tele Lights
- Driver Side Monitor: TFT Monsoon RC, Electric w/ Electric VUM, (2) Panel Controllers & (1) Wireless Controller
- Officer Side Monitor: TFT Monsoon, Manual 1250 GPM w/ Manual VUM
- Driver Side Nozzle: TFT Master Stream 1250 GPM Electric
- Officer Side Nozzle: TFT MST-4NJ Stacked Tips w/ XF-SS10 Stream Straightener
TRUCK TYPE: SPH 100 Aerial Platform
WHEELBASE: 236”
TRAVEL HEIGHT: 11’ – 6”
TRAVEL LENGTH: 46’ – 10”
CHASSIS:
PUMP: Hale
BODY: Sutphen
ADDITIONAL EQUIPMENT:
MONITOR:
-
Rescue 31
Tech Specs:
- Detroit DD13 500 hp diesel engine with Allison EV4000 automatic transmission
- 8 man cab, air conditioned for rehab
Response Info:
- Responds from station #1, Country Club Road
- Equipped for MVA and large truck accidents
- Responds to all MVAs, water, rope rescue and FAST calls.
- Should be out behnd Engine & Tower for structure fires.
- May act as a support vehicle for other calls or considered when additional lighting or power generation is needed.
Equipment Summary:
- On-spot tire chains
- Frontal and side Rollover protection System
- 25KW PTO hydraulic generator
- PTO hydraulic pump for Hurst rescue tools (Cutters, Spreaders, Combination Tools and Rams)
- Battery operated Genesis combination Tool
- Atlas Air compressor to operate pneumatic tools
- 6-bottle cascade system with booster pump
Equipment Summary Continued:
- 19-spare SCBA bottles
- LED light tower with integrated camera
- 15,000 pound winch
- 200 pound absorbent hopper
- Winch/NFPA rated anchor attachments on all four sides
- Pre-connected Hurst hydraulic rescue tools in the front bumper and left rear compartment
- 2 sets of Res-q-tec air bags and air struts
- High pressure Vetter air bags
- Oxy-acetylene and exo-thermic torches
- Metal/wood/masonry saws
- Composite cribbing
- Two grip hoists
- High angle rope rescue equipment
- FAST Team equipment
- Water/dry chemical/foam/Class D fire extinguishers
- Timbers and Plywood for shoring
-
Utility 31-1
- 2009 Ford Diesel
- 5 man cab
- 4-wheel drive
- 5 KW generator
- Quick raise HID telescoping light
- Programmable arrow/message board on top of vehicle
- Removable winch with four contact points
- Vehicle rear has the new Chevron pattern
-
Utility 31-2
- 1999 Chevrolet 3500 series 4x4
- 454 gas engine
- Automatic transmission
- Front bumper MTD winch
-
Utility 31-3
- 2015 2500HD Chevy
- 4-wheel drive
- Automatic
-
Boat 31
- February 5, 2007 Endwell Fire took delivery of a new 16-foot Rescue One Connector Boat.
- 40 hp jet drive
- Dive Platform
- This was purchased with a grant from Senator Thomas Libous.
-
Chief Vehicle Inventory
- Turnout Gear
- SCBA (Self Contained Breathing Apparatus)
- Gas Detection Meters
- Low Band Portable Radio
- High Band Portable Radio
- UHF Band Portable Radio
- Water Fire Extinguisher
- Dry Chemical Extinguisher
- Traffic Cones
- Forcible Entry Tool
- Knox Box
- Medical Bag
- AED (Automatic Exteral Defibrillator)
- Rope Throw Bag
- Life Preserver
- River Map
- Reference Books
- Map Book
- Hand Light
- Binoculars
- Flares
- Incident Planning Board
